Super audio frequency induction heating power supply installation method

The front and rear panels have obvious signs: just install according to the signs. If there is something unclear, please refer to the following figure to install.

16KW super audio frequency induction heating power supply installation diagram

26/50KW super audio frequency induction heating power supply installation diagram

80KW, 120KW, 160KW super audio frequency induction heating power supply installation diagram

1. Install the sensor: The integrated type is directly connected to the secondary pole connector of the main control cabinet. The split sensor should be reliably connected to the transformer and ensure good contact. There should be no water leakage at the water pipe interface of the sensor.

2. Cooling water connection: The inlet and outlet pipes should be connected reliably according to the instructions on the chassis label, and no wrong connections and water leakage are prohibited. It is strictly forbidden to spill water into the case. If it has occurred, immediately cut off the power supply and carry out drying treatment.

3. Grounding: Use a copper wire of 6mm2 or more and a three-phase four-wire power supply unit to connect the chassis reliably to zero. The grounding should comply with electrical specifications.

4. Remote control: connect the foot switch to the remote control interface.

5. For split induction heating equipment, you need to connect the main control cabinet and the transformer cabinet according to the corresponding wire number, and connect the induction coil connector to the transformer secondary pole connector.
